Risco LightSYS manuals

Keypad cheat sheet

• Arm (away)your codethe key with a padlock on it

  • Check the tick (Ready) icon is on; flashing slowly is fine (only the entry/exit door is open). Won't arm? Scroll to read why.
  • Key in your code, then press the Away key (the closed padlock). Three short beeps mean a wrong code: key it in again.
  • If your installer set up quick arming, the Away key on its own does it. On a Slim keypad, press Away first, then your code.
  • The keypad beeps slowly and the padlock icon flashes during the exit time. Leave and close the door.
  • Once armed, the padlock icon stays on (the LightSYS keypad's red light too). Plus and Air also show ARMED.

  Closed-padlock key	Away (full) arming
  Padlock icon flashing	Exit time: leave now
  Padlock icon steady	Armed
  Three short beeps	Wrong code: key it in again

  Pages 19, 58 and 59, 99 of the LightSYS Plus User ManualPages 6, 23 and 24 of the LightSYS 2 User Manual
• Arm while homeyour codethe key with a house on it

  • LightSYS 2 calls this Part Set; Plus and Air call it Stay. Only the perimeter zones your installer chose arm.
  • Key in your code, then press the Stay key (a house). With quick arming set up, the Stay key on its own does it.
  • During the exit time the keypad beeps, the padlock icon flashes and the house icon comes on.
  • Once armed, the house and padlock icons both stay on. Plus and Air also show AT HOME ARMED.
  • On a Slim keypad, press Stay first, then your code.

  House key	Stay (partial) arming
  Padlock icon flashing, house icon on	Exit time running
  House and padlock icons steady	Stay armed

  Pages 6, 24 and 25 of the LightSYS 2 User ManualPages 19, 60 and 61 of the LightSYS Plus User Manual
• Disarmyour codeOK

  • These keys are for the LCD and Panda keypads, where OK is the open padlock. On an Elegant, key in your code, then press its open padlock.
  • Opening the entry door starts the entry time, and the keypad beeps. Disarm before it runs out; the padlock icon goes out.
  • More than one partition? Plus and Air: press the disarm key again at All?. LightSYS 2: press 0 for all of them, then OK.
  • Disarming also silences an alarm (see Alarm memory). On a Slim keypad, press the open padlock first, then your code.
  • Under threat, key in the duress code instead of yours, then the disarm key. It disarms and silently alerts your monitoring company.

  Pages 19, 69, 71, 77, 99 of the LightSYS Plus User ManualPages 5 and 6, 28, 31 of the LightSYS 2 User Manual
• Bypass a zone

  • Each detector or door contact is a zone (LightSYS 2 says omit). Bypassing works only if your installer has turned it on.
  • Key in your code but not OK, then press the bypass key: the bent arrow (Panda: two arrows; Elegant: the down arrow).
  • Scroll to the zone and press the Stay key (a house) to change it to Y. Do the same for any other zones.
  • Press OK when done (Elegant: the tick key), then arm as usual.
  • The bypass lasts for the next arming only. A permanent bypass is in the menus, under Activities.

  Bypass key	LCD keypad: bent arrow. Panda: two arrows. Elegant: down arrow
  Stay key (a house)	Changes N to Y: the zone is bypassed
  OK (Elegant: tick)	Saves and leaves

  Pages 19, 54 to 56 of the LightSYS Plus User ManualPages 3, 5, 40 of the LightSYS 2 User Manual
• Alarm memoryyour codeOK

  • OK is the open-padlock key on the LCD and Panda keypads; on an Elegant keypad, use the tick key instead.
  • After an alarm the padlock icon flashes fast. Disarm, then scroll to see the zones that went off.
  • Later: your code, then OK (LightSYS 2: EXIT, the back-arrow key, first). Then View, OK, Alarm Memory, OK. Scroll through the last 5 alarms.
  • CALL INSTALLER on the screen? Press EXIT, then OK at Anti-Code, and read the number shown to your installer or monitoring company.
  • Key in the anti-code they give you, then press OK. The system resets.

  Pages 19, 51, 71 to 73, 99 of the LightSYS Plus User ManualPages 29 and 30, 33, 49 of the LightSYS 2 User Manual
• Chime on or offyour codeOK

  • OK is the open-padlock key on the LCD and Panda keypads; on an Elegant keypad, use the tick key instead.
  • Chime beeps the keypad when a chosen zone opens while the system is disarmed. Your installer picks the zones.
  • Key in your code and press OK (LightSYS 2: EXIT first). Go to Activities, OK, Keypad Sound, OK, then Chime, OK.
  • Choose Keypad Chime for this keypad, or Partition Chime: all keypads on Plus/Air, this partition on LightSYS 2. Press OK.
  • Scroll to ON or OFF and press OK. Plus and Air confirm with LOCAL CHIME (or GLOBAL CHIME) ON or OFF.

  Pages 19, 89, 97 of the LightSYS Plus User ManualPages 5, 22, 47 of the LightSYS 2 User Manual
• Panic alarmholdthe key with a person on it+the key with a person on itorhold4+6orhold7+9

  • Each keypad uses its own keys, listed below. Hold the pair together for 2 seconds.
  • Your installer decides whether these keys work, sound at the house and report to your monitoring company.

  LightSYS LCD keypad	Panic: the two police-officer keys. Fire: 4 and 6. Emergency: 7 and 9
  Panda keypad	Panic: the two police badge keys. Fire: 4 and 6. Emergency: 7 and 9
  Elegant keypad	Panic: the two shield keys (top and bottom right). Fire: 4 and 5. Emergency: 7 and 8
  Slim keypad	Panic: 1 and 2. Fire: 3 and 4. Emergency: 5 and 6

  Pages 20, 76 and 77 of the LightSYS Plus User ManualPages 3, 5 and 6, 32 of the LightSYS 2 User Manual
• Change a codeyour codeOK

  • OK is the open padlock on the LCD and Panda keypads (Elegant: the tick key). With the system disarmed, key in your code and press OK (LightSYS 2: EXIT first).
  • Go to Codes/Tags, OK, then Define, OK. Scroll to the user and press OK.
  • At Edit Code (Edit My Code if you aren't the Grand Master), press OK. Key in the new code and press OK.
  • One beep (ACCEPTED on Plus and Air) means it worked. Three beeps mean it didn't take.
  • The Grand Master can change any code; most users can change only their own.

  Pages 17, 19, 22, 24 of the LightSYS Plus User ManualPages 33 to 35 of the LightSYS 2 User Manual
• Set the date and timemaster codeOK

  • OK is the open-padlock key on the LCD and Panda keypads; on an Elegant keypad, use the tick key instead.
  • LightSYS Plus and Air connected to the Cloud set their own clock. On LightSYS 2, a Clock Not Set fault means it needs setting.
  • Key in the Grand Master code and press OK (LightSYS 2: EXIT first). Go to Clock, OK, then Time & Date, OK.
  • Key in the time and date as the screen shows them, moving along with the scroll keys. LightSYS 2 uses 24-hour time.
  • On LightSYS 2, the house or closed-padlock key changes date choices. Press OK to save.

  Pages 19, 87 of the LightSYS Plus User ManualPages 38, 52 of the LightSYS 2 User Manual
• Trouble lights

  • A fast-flashing power icon, or the warning triangle on a Panda, means there is a trouble.
  • Elegant: hold i for 2 seconds to see system status, or use the View menu below for troubles.
  • To read it: your code, then OK (Elegant: the tick; LightSYS 2: EXIT first). Go to View, OK, then Trouble (Fault on LightSYS 2), OK, and scroll.
  • On an LCD or Panda keypad, hold OK for 2 seconds to stop the trouble beeps.
  • Clock lost: set the time and date. Mains power lost: check the panel's power is connected and switched on. Anything else: call your installer.

  LCD/Elegant: power icon flashing fast	A trouble: see View, then Trouble
  LCD/Elegant: power icon off	No power
  Tick (Ready) off	Not ready: a zone is open
  Tick flashing slowly	Ready, with the entry/exit door open
  Padlock flashing slowly / fast	Exit time running / alarm
  House icon on	Stay armed, or a zone is bypassed
  LCD/Elegant: flame on / flashing	Fire alarm / fire circuit trouble
  Tamper icon on	Tamper alarm

  Pages 15, 19, 51, 97, 99 of the LightSYS Plus User ManualPages 5, 12, 22, 52 of the LightSYS 2 User Manual
• Send a test signal

  • LightSYS Plus and Air only: our LightSYS 2 manual doesn't show this test.
  • Key in the Grand Master code and press OK (Elegant: the tick). At Activities, press OK.
  • Scroll to Advanced and press OK, then scroll to MS Test and press OK.
  • When the screen confirms it has gone (see the table), press any key to finish.

  DONE HIT ANY KEY, and a confirmation beep	The test message has been sent to the monitoring station

  Pages 41, 95 of the LightSYS Plus User ManualPage 33 of the LightSYS Air User Manual
